Passive Rfid System Short Range RFID Reader Tablet OEM / ODM Acceptable

Product Categories

SUNSHINE RFID Technology Co.,Limited

Contact Now

Name: Passive Rfid System Short Range RFID Reader Tablet OEM ODM Acceptable
Brand: SUNSHINE
Price: 1 USD

Brand Name : SUNSHINE

Model Number : F5002

Certification : CE,ROSH

Place of Origin : CHINA

MOQ : 1

Payment Terms : T/T, Western Union

Packaging Details : Carton

Working Temperature : -25℃～+65℃

Tag Protocol : EPCglobal UHF Class 1 Gen 2 / ISO 18000-6C

Output Power : Software adjustable, step interval 1.0dB, maximum +30dBm

Reading Range : Maximum 0.5m (relate to tags type, transmitted power and application environment)

Working Frequency : 840--960 MHz

Interface Communication Rate : 115200bps

Contact Now

840-960 MHz Working Frequency tablet UHF rfid reader with short read distance

Product Advantage

Employed R2000 RF Chips, up to -82dbm receiving sensitivity and the highest performance in this field makes this module more suitable for harsh application environment.
Low power consumption, brilliant performance.
Provide the most comprehensive functions SDK and ports, easy to integrate RFID software.
Adopted integrating RF chip, module performance is more stable, and more suitable for harsh application environment.
The use of carrier wave cancellation technology makes the tags reading more accurate andreading scope wider.

Product Electrical Parameters

NO.	Name	Parameters
1	Working Voltage	DC +12V
2	Working Temperature	-25～+65℃
3	Working Humidity	≤95%(+25℃)
4	Storage Temperature	-40～+80℃
5	Tag Protocol	EPCglobal UHF Class 1 Gen 2 / ISO 18000-6C
6	Working Frequency	840--960 MHz
7	Supporting Working Areas	China 1, China 2,US, Canada and other regions following U.S. FCC, Europe and other regions following ETSI EN 302,208 with & without LBT regulations, Japan, Korea, Malaysia, Taiwan
8	Output Power	Software adjustable, step interval 1.0dB, maximum +30dBm
9	Output Power Flatness	±0.2dBm
10	Receiving Sensitivity	-82dBm
11	RF Port Standing Wave	≤1.5
12	Reading Range	Maximum 0.5m (relate to tags type, transmitted power and application environment)
13	Writing Range	Maximum 0.2m (relate to tags type, transmitted power and application environment)
14	Interface Communication Rate	115200bps
15	Working Temprature Detection	Support
16	RSSI	Support
17	Antenna Type	-1dBi ceramic antenna
18	Communication Port	USB
19	Buzzer	Yes
20	LED	Red(power indicator) Green(status indicator)
21	Enclosure	plastic case
22	Size	12.012.03.0CM

Passive Rfid System Short Range RFID Reader Tablet OEM / ODM Acceptable

Application

Product Tags:

passive rfid tag reader
